SMX-724x - Dual Slot Microwave Carrier with 1, 2 or 3 SP4T 6 GHz Switches

The VTI SMX-7xxx Series of microwave switch cards extends functionality typically reserved for dedicated stand-alone systems into the PXIe form-factor. Single and dual slot configurations provide the ability to mix and match multiple switch configurations including SPDT, SP4T, SP6T and Transfer. The pass through adapter extends functionality even further with programmable drive line ideal for attenuators and other devices. Embedded virtual schematic control further simplifies setup and debugging allowing all relays to be engaged independent of application software and device drivers.

Ideally suited for medium-to-high density automated test equipment (ATE), the SMX-7xxx Series deliver uncompromised measurement integrity ideal for the most demanding aerospace, defense and communication applications.
