UEI card DNx-AI-205 18-bit 250Ks/s 4 simultaneous channels
Technical specifications
The UEI manufacturer’s card, DNX-AI-205 is an analog acquisition card with 4 differential simultaneous sampling channels of 250Ke / s per channel, with a resolution of 18 bits and four input ranges + -0.1 V, + – 1 V, + – 10 V and + – 100V. 3-stage FIR filtering with bypass optional. The card has ± 150V surge protection (powered or not) 2000V ESD.
Software and drivers
The UEIDAQ Framework library uses the same API to access all devices of the DNx distributed cards. Using the UEIDAQ Framework library significantly reduces the amount of code required to perform data acquisition and control applications. UEI supports all 32/64 bit versions of Windows up to the most recent version of Windows 10. The UEIDAQ Framework provides a set of C ++ classes to easily interface your C ++ programs with acquisition devices UEI data. The UEIDAQ Framework also comes with an ANSI-C API. Instantly download Windows software and drivers for PowerDNA / DNR hardware from the UEI. Includes UEIDAQ Framework library, which supports the following software: VisualBASIC 6, VB.NET, LabVIEW, MATLAB, LabWindows / CVI, OPC server, Excel, .NET, C #, C / C ++, Borland Delphi, Borland C ++ Builder.
Depending on the reception station, the card references will be:
– DNA-AI-201-100 for Cubes
– DNR-AI-201-100 for Racks
– DNF-AI-201-100 for the FLATRACK
Card usable with the UEILogger.
